ZYT42-02 56 FRAME 180VDC 1/4HP 1750RPM TEFC

ZYT42-02 56 FRAME 180VDC 1/4HP 1750RPM TEFC
Item# ZYT42-02
$179.00

Product Description

Brush-type, 56-frame DC motor rated at 180 VDC, 1/4 HP and 1750 RPM. Continuous rated current of 1.4 amps and 9 Lb-In of torque. Shaft diameter of 5/8 inch with a 3/16 inch keyway. Totally Enclosed Fan Cooled (TEFC). Class F insulation system and 56C-face and foot mounts. UL Listed, File E477489. Similar to Leeson 098003.

Accessories
